CDM-570L/570AL Satellite Modem with Optional Packet Processor
Revision 5
2 (cont.) (2C cont.) Toggle [T] to enable Dump Packets transmitted to
Satellite Interface. Verify that the pings are being transmitted
by observing 1 packet on CLI every second. If not displayed,
re-verify User PC 1 and CDM-IP 1 settings. Toggle [T] to
disable Dump Packets transmitted to Satellite Interface.
D. Continue pinging from User PC 1 to User PC 2.
From the CDM-IP 2:
From the CLI Main Menu:
Select the Operations and Maintenance page [I], and then
select the Diagnostics page [G].
Toggle [R] to enable Dump Packets received from Satellite
Interface. Verify that the pings are being received by observing
1 packet on CLI every second. If not displayed, re-verify User
PC 2 and CDM-IP 2 settings. Toggle [R] to disable Dump
Packets received from Satellite Interface.
Note: All pings transmitted will require a reply to be transmitted
from the target host. Use the Diagnostics page 'Dump
Packets' tools to isolate where packets are lost in the CDM-IP
duplex paths. Also, always disable 'Dump Packets' before
sending live traffic.
Optional High Performance Packet Processor D–32 MN-CDM570A
