Comtech EF Data CDM-570A Installation And Operation Manual page 316

Command
Parameter (Instruction
Type Code and
Qualifier)
Rx E /N N/A 4 bytes
b 0
Redundancy N/A 1 bytes, 0 or 1
State
Temperature N/A 3 bytes
Offline Unit N/A 6 bytes
Status
ACM Remote N/A 4 bytes
Signal Noise Ratio
ACM Local Signal N/A 4 bytes
Noise Ratio
Serial-based Remote Product Management
Arguments for
Command or
Response to
Query
Query only.
Returns the value of E /N
b
Returns 99.9 if demod is unlocked.
For values >16.0 dB, Response = EBN=+016
Example: <0/EBN?
>0/EBN=12.3 (E
Query only.
Returns the redundancy state of the unit in the form x, where:
0 = Offline
1 = Online
Example: <0/RED?
>0/RED=1 (selects Online)
Query only.
Returns the unit internal temperature, in degrees C, in the form sxx, where:
s = sign (+ or –)
xx = value
Example: <0/TMP?
>0/TMP=+26
Query only. (1:1 set-up)
Sent to the online modem of a 1:1 pair. Returns the fault status information (FLT?)
of the offline modem in the form abcdef, where:
abcdef = The FLT? response information from the offline unit
Note: This is the only way to interrogate the status of an offline modem at the
distant-end of a link.
Query only.
Returns the value of SNR of the remote demod in the form xx.x, where:
99.9=Demod is unlocked.
xx.x=Not in ACM.
EXAMPLE: <0/RSN?
>0/RSN=12.4
Query only.
Returns the value of Local Signal Noise Ratio in the form xx.x, where:
99.9=demod is unlocked.
EXAMPLE: <0/SNR?
>0/SNR=12.3 (indicates SNR @12.3 dB)
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Description of Arguments
, from 0 to 16 dB, in the form xxxx, resolution= 0.1 dB.
0
/N = 12.3 dB)
b 0
8–50
Revision 5
Query
Response to
(Instruction Code
Command
and Qualifier)
N/A EBN? EBN=xxxx
(see Description of
Arguments)
N/A RED? RED=x
(See Description of
Arguments)
N/A TMP? TMP=sxx
(see Description of
Arguments)
N/A OUS? OUS=abcdef
(see Description of
Arguments)
N/A RSN? RSN=xx.x
(see Description of
Arguments)
N/A SNR? SNR=xx.x
(see Description of
Arguments)
MN-CDM570A
Response to
Query
