Comtech EF Data CDM-570A Installation And Operation Manual page 226

Column
Encryption
Encryption
Key
Click [Submit Changes] to save.
Add New Route
This section allows you to directly add a route entry using text boxes and drop-down lists as
described previously for the Route Table (Edit) section.
Click [Add Entry] to save. Note that, when you add a new route, the index number will
automatically increment to the next available number.
Delete Route
Enter Route Index to Delete, and then click [Delete Entry]. The specified route entry will then
be deleted from the route table.
Make sure to also click [Save PaP Parameters] on the 'Admin | PaP Save' page
before proceeding further.
7.4.3.3.4.2 Configuration | Routing | IGMP
This page permits use of Internet Group Management Protocol (IGMP) with configured multicast
routes.
IGMP, when enabled, responds to IGMP queries for the configured multicast routes on the
transmit side and generates IGMP queries on the receive side. If there are no active IGMP
receivers on the LAN, it will stop forwarding the multicast traffic (received from the satellite) to the
LAN.
Ethernet-based Remote Product Management
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Description
3xDES Encryption is a future offering and is not available in this
firmware release.
Figure 7-21. Configuration | Routing | IGMP Page
7–38
Revision 5
MN-CDM570A
