9.3.6

Protocol Configuration

Open the Protocol Configuration Page from the Main Menu.
Selection
IGMP
ARP
DHCP Server IP Address
Brouter Mode
9.3.6.1 Protocol Configuration > IGMP Information
Open the nested IGMP Information page from the Protocol Configuration page.
Use this page to view the IGMP clients that are actively listening to content being provided by the
Packet Processor. It also allows you to determine how the Ethernet Interface is configured either
to receive requests to join IGMP groups or announce groups for others to join.
Optional Packet Processor - Serial/Telnet CLI Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Figure 9-23. Protocol Configuration
Hot Key
I
Displays the IGMP page.
See Section 9.3.6.1.
A
Displays the ARP Table Utilities page.
See Section 9.3.6.2.
R
Allows entry of the DHCP server IP address.
Allows hosts on a remote LAN to send DHCP request packets to the DHCP
server so that the DHCP server can dynamically assign IP addresses to
remote hosts.
B Displays the Brouter Configuration page.
See Section 9.3.6.3.
Figure 9-24. IGMP Information
9–34
Description
Revision 5
MN-CDM570A
