FEC Type Modulation
BPSK
QPSK
8-ARY
VersaFEC-2
Short Block
16-ARY
32-ARY
BPSK
None (Uncoded)
QPSK/OQPSK
Front Panel Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Data Rate Range
Code Rate
Lower Limit
(kbps)
0.489 18.1
0.489 36.2
0.537 39.8
0.586 43.4
0.611 45.2
0.635 47.0
0.660 48.8
0.684 50.6
0.733 54.2
0.521 93.8
0.537 96.7
0.562 101.1
0.585 105.5
0.611 109.9
0.635 114.3
0.660 118.7
0.684 123.1
0.708 127.5
0.733 131.9
0.586 234.5
0.611 244.3
0.635 254.1
0.660 263.8
0.684 273.6
0.708 283.4
0.733 293.2
0.757 302.9
0.782 312.7
0.660 824.5
0.684 855.1
0.708 885.6
0.733 916.1
0.757 946.7
0.782 977.2
0.801 1001.6
0.831 1038.3
Uncoded 4.8
Uncoded 9.6
6–21
EDMAC limited?
Upper Limit
(Mbps)
0.490
0.979
1.075
1.173
1.221
1.270
1.319
1.368
1.466
1.564
1.612
1.686
1.759
1.832
1.906
1.979
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.000
3.000
Yes – see preceding
"IMPORTANT" Note 4
5.000
Revision 5
No
MN-CDM570A
