Next, do these steps on CDM-IP 2 (the applicable CLI "hot key" is shown in brackets [#]):
Step Task
8 From Transmitter Configuration Main Menu submenu select Route Table [R] submenu.
9 Enter 1 to configure the first route.
10
Enter a suitable name
11 Set IP Address to 172.17.10.0
12 Set Number of Subnet Bits to 24
13 For Interface to which route is destined to <E-Ethernet S-Satellite Enter : S> select S
14 CDM-IP 2 Route Table should display the following:
Route001...[test
At this point the basic configuration is complete and you should be able to:
•
Ping User PC 1 from User PC 2, and User PC 2 from User PC 1;
•
Ping CDM-IP 2 from User PC 1, and User PC 1 from CDM-IP 2;
•
Pass any other data between the 2 PCs
Do these steps to finish:
Step Task
15 From PC1:
Ping 172.17.10.1 (CDM-IP 1)
•
Ping 172.16.10.1 (CDM-IP 2)
•
Ping 172.16.10.11 (PC 2)
•
16 From PC2:
Ping 172.16.10.1 (CDM-IP 2)
•
Ping 172.17.10.1 (CDM-IP 1)
•
Ping 172.17.10.11 (PC 1)
•
Optional High Performance Packet Processor
CDM-570L/570AL Satellite Modem with Optional Packet Processor
Route Name Dest IP/SNet Bits
172.17.10.0/24
D–30
Next Hop MultiCast
POINT-TO-POINT N/A
Revision 5
State
toSat]
