Figure B-13. VersaFEC Codec Rates 0.533, 0.631, 0.706, and 0.803 QPSK
FEC (Forward Error Correction) Options
CDM-570A/570AL Satellite Modem with Optional Packet Processor
2 3 4
Rate Rate
0.706 0.803
QPSK QPSK
Typical performance shown -
guaranteed performance curves
2 3 4
5 6 7
Comtech VersaFEC® Codec
Rate 0.533, 0.631, 0.706,
and 0.803 QPSK
are 0.3 dB to the right
5 6 7
B–31
Eb/No in dB
8 9 10 11
8 9 10 11
