(ODU SELECT ► ODU MONITOR:) Rx
RX: Synth Tune = 03.1
IFLO = 10.9
This screen shows the Rx Synthesizer and IFLO tuning voltages and the Receiver
temperature.
(ODU SELECT ► ODU MONITOR:) Misc
MISC: Ref Tune = 03.0
LNA=000.0mA FAN=568.0mA
This screen shows the Internal Reference Oscillator tuning voltages, the LNA Current in
milliamps and the Fan Current in milliamps.
(ODU SELECT ► ODU MONITOR:) Pwr-Supp1
PS: 24V=23.8
12V=13.0
This screen monitors the first four of the six internal power supplies.
(ODU SELECT ► ODU MONITOR:) Pwr-Supp2
PS: +5V=5.5
This screen monitors the remaining two internal power supplies.
10.2.1.2.1.1.1.4
ALARMS: Current
Use the ◄ ► arrow keys to select Current or Stored, and then press ENTER.
(ODU SELECT ► ALARMS:) Current
TX = OK
PWR SUP = OK
This screen summarizes the CSAT's current operational status. If any item displays "FT"
instead of "OK" then that feature is faulted. View the Stored Events Log for further details.
(ODU SELECT ► ALARMS:) Stored
Stored Events:
Clear All
Use the ◄ ► arrow keys to select View or Clear All, and then press ENTER.
ODU (Transceiver, BUC, LNB) Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Temp = 28 oC
20V=22.6
10V=10.1
-5V=-4.9

(ODU SELECT:) Alarms

Stored
(◄ ►,ENT)
RX = OK
MISC = OK
View
(◄ ►,ENT)
