Title Box:
•
Station Type: _________________________________
•
Station Location: _____________________________
•
Equipment Rack's Configuration Revision: ________
•
Data of Last Revision: __________________________
•
Project Title: __________________________________
•
End User: ____________________________________
MULTIMEDIA INTEGRATED DIGITAL ACCESS SYSTEM
Rack Installation
Operator's Guide
MN/MID-RACK.IOM
Revision 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Comtech EF Data CIM-300L
Summary of Contents for Comtech EF Data CIM-300L
- Page 1 Title Box: • Station Type: _________________________________ • Station Location: _____________________________ • Equipment Rack’s Configuration Revision: ________ • Data of Last Revision: __________________________ • Project Title: __________________________________ • End User: ____________________________________ MULTIMEDIA INTEGRATED DIGITAL ACCESS SYSTEM Rack Installation Operator’s Guide MN/MID-RACK.IOM Revision 1...
- Page 3 Operator’s Guide Part Number MN/MID-RACK.IOM Revision 1 March 25, 2002 Comtech EF Data is an ISO 9001 Registered Company. Copyright Comtech EFData, 2002. All rights reserved. Printed in USA. Comtech EF Data, 2114 West 7 Street, Tempe, Arizona 85281 USA, 480.333.2200, FAX: 480.333.2161...
- Page 4 Comtech EF Data Customer Support Department’s document. The Level Two Contact will enter the concern into the Comtech EF Data database and determine whether the concern is a Hardware concern or a Network Operations concern...
- Page 5 Network Customer Support Plan Customer Midas Network is functioning properly? *Note: If equipment was purchased directly from Comtech EFData (not through a Factory Authorized Service Center), then CEFD Customer Support will be the initial point of contact. Level One Contact is notified Authorized Factory Service Center Resolved by Hardware repair...
- Page 6 See the Comtech EF Data website at http://www.comtechefdata.com for contact information for a Factory Authorized Service Center. Contact the Factory Authorized Service Center for: • Product support • Information on upgrading or returning a product Contact the Comtech EF Data Customer Support Department for: •...
- Page 7 Contact the Comtech EF Data Network Test and Field Support • System level Network Operations support • Information on upgrading Network Operation software • Reporting comments or suggestions concerning manuals A Network Test and Field Support representative may be reached at:...
- Page 8 This page is intentionally left blank. Rack Installation, Operator’s Guide, Rev. 1 Preface vi...
-
Page 9: Table Of Contents
Title Box ..............................1–1 Revision History............................1–1 Equipment..............................1–2 Equipment Rack Elevation ........................1–2 Equipment View ..........................1–2 Equipment Rack Wiring Diagram .......................1–2 2. Equipment View........................2–1 Equipment View ............................2–1 CiM-300L ............................2–3 CiM-550...............................2–4 CDM-550.............................2–5 CDM-600.............................2–6 SDM-300A ............................2–7 SDM-2020 Modulator .........................2–8 SDM-2020 Demodulator ........................2–9 SNM-1000 ............................2–10 SNM-1001 ............................2–11... - Page 10 This page is intentionally left blank. Rack Installation, Operator’s Guide, Rev. 1 Preface viii...
-
Page 11: About This Manual
Overview of Changes to Previous Editions Chapter 2 – Added views for CDM-550, CDM-600, CiM-550, and CiM-300L modems. Chapter 3 – Added rack instructions. Conventions and References... - Page 12 Disclaimer Comtech EF Data has reviewed this manual thoroughly in order that it will be an easy-to- use guide to your product. All statements, technical information, and recommendations in this manual and in any guides or related documents are believed reliable, but the accuracy...
-
Page 13: Introduction
Equipment The objective of this document is to record the rack location and cable connection of the Comtech EF Data provided equipment. A representation of the equipment installed into the rack, equipment front and rear panel views, and wiring diagrams also are included. - Page 14 Revision History Form Revision No. Revision Data Revision Description Documentation Administrator August 31, 2001 Initial Issue March 25, 2002 Added modems and rack instruction procedures. Rack Installation, Operator’s Guide, Rev.1 Introduction...
-
Page 15: Equipment
Data I/O Interface Type • Data Circuitry functions Views of the front and rear panels of Comtech EF Data provided equipments are included in Chapter 2 for reference purposes. The rear panel views show the connections required in the Wiring Diagram. - Page 16 Equipment Rack Number 1 Rack Location Elevation Comments RU 44 RU 43 RU 42 RU 41 RU 40 RU 39 RU 38 RU 37 RU 36 RU 35 RU 34 RU 33 RU 32 RU 31 RU 30 RU 29 RU 28 RU 27 RU 26...
- Page 17 Figure 1-2. Wiring Diagram Rack Installation, Operator’s Guide, Rev.1 Introduction...
- Page 18 This page is intentionally left blank. Rack Installation, Operator’s Guide, Rev.1 Introduction...
-
Page 19: Equipment View
For additional information, refer to the modem installation and operation manual. Identifiers for various band frequencies are not included and reference shall be made to the individuals installation and operation manual. Comtech EF Data Equipment SNM-1000 Node Control Modem SNM-1001... - Page 20 This page is intentionally left blank. Rack Installation, Operator’s Guide, Rev.1 Equipment View...
- Page 21 SNM-1000 Physical: 1 RU Size: 1.75H x 19W x 15.7D inches (4.4 x 48 x 40D cm) ≤ 9 lbs (≤ 4 kg) Weight: Rack Installation, Operator’s Guide, Rev.1 Equipment View 2-3...
- Page 22 SNM-1001 Physical: 1 RU Size: 1.75H x 19W x 20D inches (4.4 x 48 x 51 cm) Weight: ≤ 9 lbs (≤ 4 kg) Rack Installation, Operator’s Guide, Rev.1 Equipment View...
- Page 23 SNM-1002 Physical: 1 RU Size: 1.75H x 19W x 16D inches (4.4 x 48 x 40 cm) Weight: ≤ 11 lbs (≤ 5 kg) Rack Installation, Operator’s Guide, Rev.1 Equipment View...
- Page 24 SNM-1010 Physical: 1 RU Size: 1.75H x 19W x 16D inches (4.4 x 48 x 40 cm) Weight: ≤ 9 lbs (≤ 4 kg) Rack Installation, Operator’s Guide, Rev.1 Equipment View...
- Page 25 SNM-1010L Physical: 1 RU Size: 1.75H x 19W x 16D inches (4.4 x 48 x 40 cm) Weight: ≤ 9 lbs (≤ 4 kg) Rack Installation, Operator’s Guide, Rev.1 Equipment View...
-
Page 26: Cim-300L
CiM-300L Physical: Size: 1.75H X 19.0W X 19.0 D inches (4.4H x 48W x 48D cm) Weight: ≤ 9 lbs (≤ 4 kg) Rack Installation, Operator’s Guide, Rev.1 Equipment View... -
Page 27: Cim-550
CiM-550 Physical: Size: 1.75H x 19.0W x 18.0D inches (4.4 x 48.0 x 46 cm) Weight: ≤ 9 lbs (≤ 4 kg) Rack Installation, Operator’s Guide, Rev.1 Equipment View... -
Page 28: Cdm-550
CDM-550 Physical: 1 RU Size: 1.75H x 19.0W x 18.0D inches (4.4 x 48.0 x 46 cm) Weight: ≤ 9 lbs (≤4 kg) Rack Installation, Operator’s Guide, Rev.1 Equipment View 2-10... -
Page 29: Cdm-600
CDM-600 Physical: 1 RU Size: 1.75H x 19.0W x 13.13D inches (4.4 x 48 x 33.3 cm) Weight: ≤ 9 lbs (≤ 4 kg) Rack Installation, Operator’s Guide, Rev.1 Equipment View 2-11... -
Page 30: Sdm-300A
SDM-300A Physical: 1 RU Size: 1.75H x 19.0W x 14.0 inches (4.4 x 48 x 36 cm) Weight: 9 lbs (4 kg) Rack Installation, Operator’s Guide, Rev.1 Equipment View 2-12... -
Page 31: Sdm-2020 Modulator
SDM-2020 Modulator PRIME POWER GROUND FUSE HOLDER J1 REMOTE J2 FAULT DATA INTERFACE CONNECTIONS CP1 TX-IF Physical: 1 RU Size: 1.75 H x 19W x 14D inches (4.4 x 48 x 36 cm) Weight: < 15 lbs (<7 kg) Rack Installation, Operator’s Guide, Rev.1 Equipment View 2-13... -
Page 32: Sdm-2020 Demodulator
SDM-2020 Demodulator Physical: 1 RU Size: 1.75H x 48W x 14D inches (4.4 x 48 x 36 cm) Older chassis 1.75H x 48W x 16D inches (4.4 x 48 x 41 cm) New chassis Weight: ≤ 15 lbs (≤ 7 kg) Rack Installation, Operator’s Guide, Rev.1 Equipment View 2-14... - Page 33 SMS-301 DEMOD J1 REMOTE SWITCH CONTROL RX IF TX IF 100 TO 240V 1.5 A 50 TO 60 Hz REMOTE MODEM STATUS/FAULTS T2A, 250V CONTROL Physical: 1 RU Size: 1.75H x 19W x 15D inches (4.4 x 48 x 39 cm) Weight: <...
- Page 34 This page is intentionally left blank. Rack Installation, Operator’s Guide, Rev.1 Equipment View 2-16...
-
Page 35: Required Equipment
Each rack shall use an addition manual to record all the vital information relating to that rack installation. Additional information can be obtained via the Comtech EF Data Network Customer Support department. The following equipment shall be available for the rack installation. This equipment may be obtained from Comtech EF Data, Sales and Marketing department. -
Page 36: Typical Rack Installation
The MIDAS System will not accept the Comtech EF Data SDM-300A with Mux, Flex Mux, or the 100-pin J8 I/O connector installed. IMPORTANT The user shall construct a workstation to their specification, using the equipment recommended by Comtech EF Data. Figure 3-1 illustrates a basic workstation. -
Page 37: Sms-301
Local Client Workstation Combiner Low Latency High Speed Connection Remote Security Key HPOV HPOV Combiner (Dongle) Client Controller FASTCOM Y-Cable Interface RS422 RS232 Figure 3-1. FASTCOM Y-Cable Connection (Reference Only) Rack Installation, Operator’s Guide, Rev.1 Typical Rack Installation... -
Page 38: Rack Installation
Located in Chapter 1 is the Equipment Rack form, each rack will have a form completed to maintain continuity of the installation. Use this form to build the rack, as follows. Figure 3-2. Typical Rack Installation (30-Channel) Rack Installation, Operator’s Guide, Rev.1 Typical Rack Installation... -
Page 39: Snm-1001
Equipment Rack Number 1 Rack Location Elevation Comments RU 44 SNM-1000 RU 43 SNM-1001 RU 42 SNM-1002 RU 41 SDM-300A Channel # 1 RU 40 SDM-300A Channel # 2 RU 39 SDM-300A Channel # 3 RU 38 SDM-300A Channel # 4 RU 37 CDM-550T Channel # 5 [Data only]... -
Page 40: Wiring Connections
Connect Adapter P/N CA/WR9440 as appropriate : Connect Adapter P/N CA/WR9440 to all Comtech EF Data CDM modems installed in the equipment rack, at the REMOTE CONTROL port. Connect Adapter P/N CA/WR9440 to all Comtech EF Data CiM modems installed in the equipment rack, at the IP REMOTE port. -
Page 41: Equipment Rack History
Located on the cover of this manual is the Title Box, fill in the required information for each equipment rack, as shown in the following sample: Title Box: • Station Type: ABCDE_______________________ • Station Location: Phoenix, Arizona_______________________ • Equipment Rack’s Configuration Revision: AA_____ •... - Page 42 This page is intentionally left blank. Rack Installation, Operator’s Guide, Rev.1 Typical Rack Installation...
- Page 43 METRIC CONVERSIONS Units of Length Unit Centimeter Inch Foot Yard Mile Meter Kilometer Millimeter 1 centimeter — 0.3937 0.03281 0.01094 6.214 x 10 0.01 — — 1 inch 2.540 — 0.08333 0.2778 1.578 x 10 0.254 — 25.4 1 foot 30.480 12.0 —...
- Page 44 2114 85281 WEST TH STREET TEMPE ARIZONA 480 • 333 • 2200 PHONE 480 • 333 • 2161...
