8.5.8

BUC (L-Band Block Up Converter) Commands and Queries (CDM/R-570AL ONLY)

Command
Parameter (Instruction
Type Code and
Qualifier)
Attach ABA= 1 byte, 0 or 1
summary BUC
fault to Tx FLT
status
BUC Address BAD= 2 bytes,
value of 01 to 15
BUC Comms BCE= 1 byte,
enable value of 0 or 1
BUC High Current BCH= 4 bytes
Limit
BUC Low Current BCL= 4 bytes
Limit
BUC Current N/A 4 bytes
BUC Voltage N/A 4 bytes
Serial-based Remote Product Management
Arguments for
Command or
Response to
Query
Command or Query.
Sets or returns BUC fault-to-Tx fault disposition in the form x, where:
0 = Tx FLT status unaffected by BUC fault
1 = Attach a summary BUC fault to Tx FLT status
Command or Query.
Sets or returns the BUC Address, in the form xx, where:
xx = address from 01 to 15.
Example: <0/BAD=03
Command or Query.
Sets or returns communications, via the FSK link, with an externally connected
Block Up Converter (BUC) in the form x, where:
0 = Disabled
1 = Enabled
Example: <0/BCE=0 (Disabled)
Command or Query.
Sets or returns BUC High Current Limit, in mA, the form xxxx, where:
xxxx = value from 500 to 4000
Example: <0/BCH=3100
Command or Query.
Sets or returns BUC Low Current Limit, in mA, the form xxxx, where:
xxxx = value from 0 to 3000
Example: <0/BCL=0600
Query only.
Returns BUC Current, in mA, in the form xxxx, where:
xxxx = value from 0 to 9999
When unavailable, response is 0000.
Example: <0/BDC=3100
Query only.
Returns BUC Voltage, in the form xx.x, where:
xx.x = value from 0 to 64.0
When unavailable, response is 00.0.
Example: <0/BDV=43.6 (BUC DC voltage is 43.6 volts)
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Description of Arguments
8–58
Revision 5
Query
Response to
(Instruction Code
Command
and Qualifier)
ABA= ABA? ABA=x
ABA? (see Description of
ABA* Arguments)
ABA#
BAD = BAD? BAD=xx
BAD? (see Description of
BAD * Arguments)
BAD #
BCE= BCE? BCE=x
BCE? (see Description of
BCE* Arguments)
BCE#
BCH= BCH? BCH=xxxx
BCH? (see Description of
BCH* Arguments)
BCH#
BCL= BCL? BCL=xxxx
BCL? (see Description of
BCL* Arguments)
BCL#
N/A BDC? BDC=xxxx
(see Description of
Arguments)
N/A BDV? BDV=xx.x
(see Description of
Arguments)
MN-CDM570A
Response to
Query
