Configuration | Routing - Comtech EF Data CDM-570A Installation And Operation Manual

Add Static ARP
This section allows you to directly add a static ARP entry. Note that the index number will
automatically increment to the next available number.
Click [Add Entry] to save.
Delete Static ARP
Enter Entry Index to Delete, and then click [Delete Entry]. The entry will then be deleted from
the ARP table.
Flush Dynamic ARPs
Click [Flush ARP Table] to delete all dynamically learned ARP entries.
Make sure to also click [Save PaP Parameters] on the 'Admin | PaP Save' page
before proceeding further.
7.4.3.3.4 Configuration | Routing Pages
1. These pages are available only to Admin users and when you install the
optional Packet Processor.
2. If you submit any changes to these pages, you must also open the 'Admin |
Pap Save' page (see Sect. 7.4.3.2.8) and immediately click [Save PaP
Parameters].
Click the Routes, IGMP, or DHCP tab to continue.
7.4.3.3.4.1 Configuration | Routing | Routes
Use this page to enter static routes into the Packet Processor to route IP traffic over the satellite
or to another device on the local LAN.
Ethernet-based Remote Product Management
CDM-570A/570AL Satellite Modem with Optional Packet Processor
7–36
Revision 5
MN-CDM570A
