QUESTION: What is the total output data rate and what are the individual port output data rates?
ANSWER:
•
The QoS system first drains Priority 1 traffic. Since the management data stream is only
200 Kbps, after serving Priority 1 traffic, QoS still has 9.8 Mbps (10.0-0.2=9.8).
•
QoS next drains Priority 2's 800 Kbps traffic. After the end of the Priority 2 traffic, QoS
still has 9 Mbps traffic available (9.8-0.8=9).
•
Similarly, QoS walks through all priorities until it hits the ASFD classes:
o
The beginning of ASFD Classes QoS leftover bandwidth is 2 Mbps.
o
All ASFD classes have the same Priority of 7, with different service rates.
o
ASFD service rate is a Committed Information Rate (CIR), except serviced if
bandwidth available after serving all high priority queues. In this case, 2 Mbps
bandwidth is available, serving all service rates first. The total of all ASFD service
rates are 1.6 Mbps, which is less than the 2 Mbps leftover bandwidth.
o
After serving the service rates, the leftover bandwidth is 400 Kbps. This 400 Kbps will
be distributed to all ASFD classes equally in round robin fashion until either there is
no more bandwidth, or the input streams have no data.
The resulting individual data rates are as follows:
Stream
Management
Networking Control
Voice
Video
Data-1
Data-2
Data-3
Data-4
Data-5
Data-6
Data-7
Total
Advanced Quality of Service (QoS) Option
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Priority PHB / DSCP Code
1 CS7 / b111000
2 CS6 / b110000
3 EXFD / b101110
3 CS5 / b101000
4 CS4 / b100000
5 CS3 / b011000
7 ASFD4 / b100010
7 ASFD3 / b011010
7 ASFD2 / b010010
7 ASFD1 / b001010
8 BE / bXXXXXX
N/A N/A
L–10
Drop
Service Rate
Precedence
200 Kbps 9.8 Mbps
800 Kbps 9.0 Mbps
1 Mbps 8.0 Mbps
4 Mbps 4.0 Mbps
550 Kbps 3450 Kbps
1450 2000 Kbps
1 Mbps NA
1 Mbps NA
1 Mbps NA
1 Mbps NA
2 Mbps NA
14 Mbps 0 Kbps
Revision 5
Data Rate
200 Kbps
800 Kbps
1Mbps
4 Mbps
550 Kbps
1450 Kbps
100 + 100 Kbps
400 + 100 Kbps
500 + 100 Kbps
800 + 100 Kbps
0 Kbps
10 Mbps
