P.10.2

VersaFEC-2 ACM

System Type
Symbol Rate Range
Interface
Remote SNR Reporting
Max Span of Data Rate
Switch Point (decreasing SNR)
Switch Point Hysteresis
Max Fading Rate
Max ModCod Update Rate
Configurable Parameters
System Latency @ 100 ksps
Monitored Parameters
List of ModCods
Adaptive Coding and Modulation (ACM) Option
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Adaptive Coding and Modulation, using BPSK, QPSK, 8-ARY, 16-ARY, 32-ARY and
VersaFEC-2 Short-block and Long Block LDPC coding - total of 74 ModCods
5 ksps to 3.0 Msps (Long)
10/100 Base T Ethernet, with auto-negotiated Congestion Control
Automatically reported from remote modem – built in function at the physical
layer – requires no additional overhead
9:1 over range of adaptation
Corresponds to SNR (Es/No) that gives BER = 1 x 10
0.3 dB
Approximately 1 dB/second (higher if Target Eb/No margin > 1 dB)
1 update every 1.7 seconds
Maximum ModCod (ModCod00 through ModCod37, Long Block)
•
Maximum ModCod (ModCod00 through ModCod35, Short Block)
•
Remote Demod Unlock Action: Go to minimum ModCod
•
Target SNR margin (0 to 4.5 dB, 0.5 dB steps)
•
Long Block - 205 milliseconds max (not including WAN buffer, or satellite path)
Short Block – 40.4 milliseconds max (not including WAN buffer, or satellite path)
Tx and Rx ModCods
•
Local and Remote SNR
•
(-3.0 dB to +22.0dB, 0.1dB resolution, +/- 0.5 dB accuracy)
Config and monitor menus displaying data rate, modulation and code rate update
•
dynamically with ModCod
See Appendix B, Tables B-6 and B-7
P–20
Revision 5
(margin set to 0 dB)
-8
MN-CDM570A
