D.3 High-Performance Packet Processor – Typical Operational Setups
The CDM-570A/570AL-IP Satellite Modem (referred to hereafter as the CDM-IP) has several
modes of operation. To determine the best mode of operation for the appropriate network
topology and Ethernet traffic environment, this appendix illustrates typical operational setup
examples for the CDM-IP.
D.3.1.1 High-Performance Packet Processor Working Modes
Two Packet Processor Working Modes are available: Managed Switch Mode (formerly
TM
easyConnect ) and Router Mode.
D.3.1.1.1 Working Modes – HDLC Encapsulation
COMPATIBILITY NOTE – HDLC Encapsulation is available only in CDM-570/L or
CDD-564/L IP Module V1/MPP-50 Firmware Ver. 1.6.# and earlier, and IP Module
V2/MPP-70 Firmware Ver. 2.1.# and earlier.
Three HDLC Addressing Modes serve to minimize the HDLC overhead transmitted over the
satellite based upon the size of their network. These modes are:
•
Point-to-Point
In order to optimize Comtech EF Data IP modems in the network (based upon Network Topology
and Ethernet Traffic requirements), note the following:
•
In Router/Point-to-Point Mode, no HDLC address is transmitted.
•
Router/Small Network Mode transmits 1 byte.
•
Router/Large Network Mode transmits 2 bytes as part of the HDLC header for each
packet; non-IP traffic is not supported in Router Mode.
The Working Mode and HDLC Addressing Mode of the Comtech EF Data IP
modems must be identical to pass traffic between modems.
Changing the Working Mode or HDLC Addressing Mode of the IP modem
requires the Packet Processor to be rebooted. Before selecting a different
mode, the Packet Processor issues a notice that the mode change will require a
reboot.
Managed Switch Mode
Point-to-Point
Router Mode
Point-to-Point
Router Mode
Small Network
Optional High Performance Packet Processor
CDM-570L/570AL Satellite Modem with Optional Packet Processor
•
Working Mode
HDLC Addressing Mode
Small Network
Network Topology
Point-to-Point only
Both sites on same LAN subnet
Point-to-Point only
Both sites on different LAN subnet
Point-to-Point or Point-to-MultiPoint
(up to 254 sites)
All sites on different LAN subnet
D–34
Revision 5
•
Large Network
Ethernet Traffic
IP v4 and/or non-IP
IP v4 only
IP v4 only
MN-CDM570A
