Comtech EF Data CDM-570A Installation And Operation Manual page 295

Command
Parameter (Instruction
Type Code and
Qualifier)
Statistics Sample SSI= 1 byte,
Interval numerical
Number of Unread N/A 3 bytes
stored Statistics
Clear All Stored CAS= None
Statistics
Initialize Statistics ISP= None
Pointer
Retrieve Next 5 N/A 130 bytes
unread stored
Statistics
Serial-based Remote Product Management
Arguments for
Command or
Response to
Query
Command or Query.
Sets or returns the sample interval for the Statistics Logging Function in the form x,
where:
x = 0 to 9 in 10 minute steps.
Note: Setting this parameter to 0 disables the statistics logging function.
Example: <0/SSI=3 (30 minutes)
Query only.
Returns the number of stored statistics that remain unread over the remote interface
in the form xxx.
Example: <0/NUS?
>0/NUS=247
Command only.
This command takes no arguments.
Forces the software to clear the software statistics log
Command only.
This command takes no arguments.
Resets internal pointer to allow RNS? queries to start at the beginning of the
statistics log.
Query only.
Returns the oldest 5 Stored Statistics that remain unread over the remote interface
in the forms:
For non-IP-ACM modes:
{CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Subbody{CR}Sub-body
where Sub-body = AA.ABB.BC.CD.Dddmmyyhhmmss:
AA.A=Minimum Eb/No during sample period.
BB.B=Average Eb/No during sample period.
C.C=Max. Tx Power Level Increase during sample period.
D.D=Average Tx Power Level Increase during sample period.
ddmmyyhhmmss = date/time stamp.
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Description of Arguments
8–29
Revision 5
Query
Response to
(Instruction Code
Command
and Qualifier)
SSI= SSI? SSI=x (see
SSI? Description of
SSI* Arguments)
SSI#
N/A NUS? NUS=xxx (see
Description of
Arguments)
CAS= N/A N/A
CAS?
CAS*
CAS#
ISP= N/A N/A
ISP#
N/A RNS? RNS={CR}AA.ABB.
BC.CD.Dddmmyyh
hmmss{CR}AA.AB
B.BC.CD.Dddmmyy
hhmmss{CR}AA.AB
B.BC.CD.Dddmmyy
hhmmss{CR}AA.AB
B.BC.CD.Dddmmyy
hhmmss{CR}AA.AB
B.BC.CD.Dddmmyy
hhmmss
(see Description of
Arguments)
MN-CDM570A
Response to
Query
