CDM-Qx Satellite Modem
Ethernet Management (Base Modem)
11.4
SNMP Interface
The Simple Network Management Protocol (SNMP) is an application-layer protocol
designed to facilitate the exchange of management information between network devices.
The CDM-Qx SNMP agent supports both SNMPv1 and v2c.
IMPORTANT
11.4.1
Management Information Base (MIB) Files
MIB files are used for SNMP remote management and consist of Object Identifiers (OIDs).
Each OID is a node that provides remote management of a particular function. A MIB
file is a tree of nodes that is unique to a particular device.
There are three MIB files associated with the CDM-Qx:
MIB File/Name
fw10874-2-.mib
ComtechEFData
MIB file
fw11247-1- .mib
CDM-Qx MIB file
fw11247-2- .mib
CDM-Qx Traps
MIB file
These MIB files should be compiled in a MIB Browser or SNMP Network Monitoring
System server.
The SNMP agent supports both "SNMPv1" and "v2c". The "Traps" file only
Note:
needs to be compiled if "SNMPv1" traps are to be used.
For proper SNMP operation, the CDM-Qx MIB files must be used with
the associated version of the CDM-Qx base modem M&C. Please refer
to the CDM-Qx SW Release Notes for information on the required
FW/SW compatibility.
Description
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data products and
consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full
path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFData(6247)
Module: ComtechEFData
MIB file consists of all of the OIDs for management of the modem functions
Trap MIB file is provided for SNMPv1 traps common for base modems.
11–8
Revision 6
MN/CDMQx.IOM
