Use the arrow keys to Disable or Enable the warm-up delay feature. Press ENTER.
If you select Disable, the modem powers up, and goes into normal operational service without
delay.
If you select Enable, one of the following screens displays when the modem powers up:
CDM/R-570ALunit:
Comtech CDM/R-570ALModem
Ref Warming-up: 045
The bottom line counts down, in seconds, the time remaining for the warm-up period. During this
period, the Tx Carrier is deliberately muted. At the end of the warm-up period, the bottom line
reverts to the 'normal' opening screen display (i.e., it displays the Firmware version), and the
modem ENTERs into its normal operational state.
Bypass (override) the warm-up period at any time by pressing the CLEAR key.
6.3.7.4

UTIL: CMO

Compatible Mode: CDM-570
CDM-570A
◄ ►
Use the arrow keys to select the modem model type. Press ENTER.
6.3.7.5

UTIL: ID (Circuit ID)

Edit Circuit ID:(◄ ►,▲ ▼)
-------------------------
A 24-character Circuit ID string may be composed on the bottom line only. To compose the
Circuit ID string, first use the
▲▼arrow keys to edit that character. Press ENTER.
Use the following characters to compose a Circuit ID string or (a maximum length of 24
characters of allowed):
6.3.7.5.1

UTIL: 1:1 (Manual 1:1 Switchover)

1:1 Manual/Auto
If this modem is the online unit in a 1:1 redundant configuration, press ENTER to force the unit
into Standby mode. Otherwise, press CLEAR to exit this menu and return to the previous menu
without causing the switchover.
Front Panel Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
(◄ ►,ENTER)
◄ ►
arrow keys to select a character to edit. Then, use the
[Space] ( - . / 0 through 9 and A through Z.
) * +
Force
CDM-570A unit:
Comtech CDM-570A Modem
Ref Warming-up: 045
