9.3.2.1 Administration > Name/Password Configuration
Open the nested Name/Password Configuration page from the Administration page.
Use this page to define the passwords required to access via HTTP, FTP, and Telnet.
•
All Usernames and Passwords are case sensitive.
•
There is a minimum of 1 and maximum of 11 characters.
•
You may remove any or all of the Usernames and Passwords by typing
"NONE NONE" after each selection.
•
Removing all Usernames and Passwords allows access only to the IP
functions when connecting via the Terminal Emulator serial connection
(because there is no log in).
•
FTP access is restricted to Admin Username/Password only. FTP is only
used to update the Packet Processor firmware or to load or retrieve the IP
Parameter or IP Event log files.
Selection
Admin User/Password
Read/Write User/Password
Read Only User/Password
Optional Packet Processor - Serial/Telnet CLI Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Figure 9-4. Name/Password Configuration
Hot Key
A
Set the User Name and Password with a space delimiter.
W
Example: <user> <password>
R
Type NONE NONE to erase.
9–9
Description
MN-CDM570A
Revision 5
