The page provides these read-only statistics for Filtered or Dropped Packets:
Packet
Type
Filtered Boot
Flow Descriptor
Unknown Reason Code
Flow Correlator
Management Path
Wan scaling
Ping
Access Control
Vipersat MCP
Vipersat UCP
Codeload
Multicast
Bad Packet
Route
Vipersat Remote
QoS Rule
Vipersat Loop
Bad Header Len
Bad Data Ptr
MAC Split Err
L3Type Err
Local Destination
Redundancy Err
ICMP Filter
Port Err
Optional Packet Processor - Serial/Telnet CLI Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Feature
Packets are filtered while booting.
• Packets are Filtered due to a Multicast packet classified as
UNICAST packet.
• Packets are filtered due to offline modem receiving packet from
WAN port.
Packets dropping due to reasons not listed here.
Packet are filtered due to improper establishing SAT-to-SAT traffic
(This counter generally is seen on outbounding Hub modem in point-
to-multipoint setup)
Not used.
Internal Error occurred during WAN scaling sub process in processing
packet.
Ping packets were received but PING feature was Disabled.
Packets are received while "Access List" control is Enabled but IP
address does not match the access list database.
Internal Error occurred while processing Vipersat Multi-command
messages.
Internal Error occurred while processing Vipersat Uni-command
messages.
Internal error occurred while processing Codeload messages.
A Multicast packet is received but no application is associated with it.
Malformed packet is received. This may be due to internal or external
error
Applies to Vipersat Remote only – when a packet is received from the
WAN and the Route Table contains a route to transmit that packet to
the WAN, the packet is filtered to prevent a routing loop.
Packets are filtered due to Vipersat Remote mode (a modem
configured as a Vipersat Remote Expansion unit and default route set
to 0.0.0.0/0).
Packet filtered due to QoS Rule configured to filter.
Packets are filtered due to WAN loop in Vipersat Remote mode
Filtered due to packets received with less than 14 bytes of L2 header.
Internal error occurred while accessing the packet data.
Not currently used.
Not currently used.
Packet received with destination MAC as modem MAC and destination
IP is not modem IP while modem is operating in bridge mode
(Managed Switch)
Applies to Offline modem in 1:1 Redundancy
Packets are received on the WAN port by the both Offline unit and
Online unit, only Online unit is allowed to forward the packets.
Indicates packets received by Offline unit from WAN port that were
filtered because unit is Offline.
This is the same as "Filtered Ping", except this will update in Managed
Switch mode.
Non-IP or ARP packets are targeted to End-station. (End-station will
not allow any non-Packets).
