Comtech EF Data CDM-570A Installation And Operation Manual page 349

You must set the Traffic Port Speed/Mode to match the Ethernet port settings of
the connected device port to avoid experiencing significant performance
degradation.
For example, if the connected device port is set for Auto Negotiate, then you
must also set the Packet Processor to Auto Negotiate. Comtech EF Data
recommends that you use Auto Negotiate mode, unless the connected device
port does not support Auto Negotiate. In such cases, both Ethernet ports must be
set to the same Manual settings (i.e., 100 Mbps Full Duplex).
Selection
Mgmt MAC Address
Traffic Port Speed/Mode
Mgmt IP Address
Subnet Prefix Length
DM/Red Traffic MAC Address
Traffic Port Actual Speed
Managed Switch MAC
Learning
Managed Switch Gateway IP
Dedicated Management Port
VLAN
VLAN Table
Optional Packet Processor - Serial/Telnet CLI Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Hot Key
[RO] This is the hardware destination MAC Address that is used when an
Ethernet packet is destined for the Packet Processor M&C Ethernet
Interface. This address is unique and has been assigned permanently
at the factory.
E This is a configurable parameter and, as such, its exact setting can
vary between specific installations. The default setting allows the
Ethernet port to auto-negotiate its link speed on power-up. Selections
are:
1 – Auto (default)
2 – 10 MB/sec Half Duplex
3 – 100 MB/sec Half Duplex
4 – 10 MB/sec Full Duplex
5 – 100 MB/sec Full Duplex
I Select this to assign the IP Address for the Ethernet M&C Interface.
Set the IP address in aaa.bbb.ccc.ddd format
M
Select this to define the Subnet Mask assigned to the Ethernet Traffic
Interface.
Set the subnet mask prefix length (8...30)
[RO] This is the hardware destination MAC Address that is used when an
Ethernet packet is destined for the Packet Processor Traffic Ethernet
Interface. This address is unique and has been assigned permanently
at the factory.
[RO]
This displays the current speed and duplex of the Packet Processor
Traffic port.
A Select this to disable MAC Learning on packets received on the
Ethernet Interface, so that all packets are sent to the satellite.
G Select this to define a Gateway so that the Packet Processor is
accessible from an outside network when in Managed Switch Mode
D Select this to disable or enable Dedicated Management Port operation.
When Working Mode = Managed Switch, selections are:
1 – Disabled (default)
2 – Local ONLY mode
3 – Local & Remote Mode
Appendix Q. DEDICATED MANAGEMENT PORT
FEATURE
V
Select this to enable VLAN support functions
T Select this to create VLAN Table entries – see Sect. 9.3.3.1.1.1
9–21
Description
MN-CDM570A
Revision 5
