2. Next, create a temporary folder (subdirectory) on the User PC for the firmware archive
download.
There are several ways to create a temporary folder on a Windows-based PC:
a. Use the Windows Desktop to create and rename the temporary folder.
Updating Firmware
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Using the CDM-570A/570AL Serial Remote Interface (via the User PC /
terminal emulator program):
•
Firmware Info – Use the <0/SWR? (condensed) or <0/FRW? (detailed)
remote query.
•
Ethernet Traffic IP Address – Use the <0/IPA? remote query.
•
Drive letter "c:" is used in these examples. Any valid, writable drive
letter can be used.
•
Typical for all tasks: Type the command without quotes, and then
press Enter to execute.
•
Right-click anywhere on the desktop to open the popup submenu, and then
select New > Folder to create a temporary folder on the desktop.
•
Right-click on the new folder and then select "Rename" from the popup
submenu. Rename this folder to "temp" or some other convenient, unused
name.
4–6
Revision 5
MN-CDM570A
