If you are a Base Modem user, the CDM-570A/570AL is now operating with
its latest firmware and you may skip to Step 6. However, if you are running a
CDM-570A/570AL with the optional Packet Processor installed, do NOT
reboot at this time – once you have uploaded the Base Modem firmware you
must proceed to the next step (Step 3) to upload the Packet Processor
firmware.
3. Before you can upload the Packet Processor firmware, you must first specify which
firmware slot will receive the firmware update file transfer.
•
On the CDM-570A HTTP Interface 'Admin | Firmware | Packet Processor' page,
use the 'Upgrade To' drop-down list to select Latest, Image 1, or Image 2.
•
Click [Submit] to save.
Proceed once you have specified the file transfer destination slot.
4. Use Command-line to initiate the FTP session with the modem.
a. Type "ftp xxx.xxx.xxx.xxx" (where 'xxx.xxx.xxx.xxx' is the CDM-570A/570AL
Ethernet Traffic/Management IP Address).
b. Enter the Admin User Name and Password to complete login.
c. Type "bin" to set the binary transfer mode.
d. Type "prompt", and then type "hash" to facilitate the file upload.
e. Type "put FW-0020781*_CDM-570A_PaP_#_#_#.bin" to begin the file upload.
It will take several minutes to transfer and write the files to flash memory. Once the
file transfers, Command-line displays the upload result, similar to:
f. Once the FTP upload is complete, as the upgrade process continues, the modem
front panel displays:
g. The process sequences through several blocks – this will take several minutes. Once
the update process is complete, the modem front panel displays:
Press the modem front panel CLEAR key as prompted.
h. Type "bye" to terminate the FTP session, and then close the Command-line window.
Updating Firmware
CDM-570A/570AL Satellite Modem with Optional Packet Processor
200 Port OK
150 Opening data connection
226 Packet Processor upgrade complete – Safe to reboot.
ftp: XXXXXXXX bytes sent in X.XXSeconds XXXX.XXKbytes/sec.
IP OPTION CARD UPGRADING
..PLEASE WAIT
Upgrade finished
Press CLEAR to continue.
