Comtech EF Data CDM-570A Installation And Operation Manual page 367

Selection
VLAN Brouter Remote
Mode Enable
VLAN Filtering
VLAN ID 1 through 10
Optional Packet Processor - Serial/Telnet CLI Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Hot Key
R Toggle as [Enabled] or [Disabled].
In this mode, IP traffic received from the WAN interface will not be
forwarded back to the WAN interface, even though the route table
matches.
Each remote modem must have Remote Mode enabled,
indicating this is a distant-end modem.
F Toggle bridging for all "Brouted" VLAN destination packets and routing of
non-VLAN traffic as [Enabled] or [Disabled].
0001
Assign a numeric VLAN ID in the range from 0001 to 4094.
thru
4094
The VLAN ID is a 12-bit field in the Ethernet packet that
contains the IEEE-802.1Q tag.
VLAN ID 0001 is reserved and used for normal switch
•
operation.
A maximum of 10 VLAN ID matches are supported.
•
Unused VLAN ID match fields must be set to values that
DO NOT match any network VLAN IDs.
9–39
Description
Revision 5
MN-CDM570A
