8.5.5

Bulk Configuration Commands and Queries

Command
Parameter (Instruction
Type Code and
Qualifier)
OGC Outdoor Unit OGC= 50 Bytes
Global
Configuration
Global MGC= 200 bytes, with
Configuration in numerical entries,
CDM-570A fixed values, and
Compatible Mode delimiters.
(CMO=1)
Serial-based Remote Product Management
Arguments for
Command or
Response to
Query
Command or Query – CDM/R-570AL only.
Sets or returns ODU Global Configuration of CDM/R-570AL in the form
aabcdexxxxhhhhiiiijjjjjkxxxxxxlmnnnooopppppqxxxxxx, where:
aa = BUC Address
b = BUC FSK comms enable
c = BUC Power Control
d = BUC 10MHz Frequency Reference enable
e = BUC Tx Output Enable
xxxx = expansion bytes
hhhh = BUC Low Alarm Limit
iiii = BUC High Alarm Limit
jjjjjk = BUC LO frequency, mix sign
xxxxxx = expansion bytes
l = LNB Power Control
m = LNB 10MHz Frequency Reference enable
nnn = LNB Low Alarm Limit
ooo = LNB High Alarm Limit
pppppq = LNB LO Frequency, mix sign
xxxxxx = expansion bytes
Any unavailable parameters will be filled with xxx.
Command or Query.
Sets or returns Global Configuration of CDM570AL, in CDM-570A Compatible
Mode (CMO=1), in the form shown in Response to Query column, where:
a = Unit Interface Type
b = T1 Line build-out
c = Unit Framing mode
dddd.dddd = Tx Frequency
e = Tx FEC Type
f = Tx Modulation type
g = Tx FEC Rate
hhhhh.hhh = Tx Data Rate
i = Tx Spectrum Inversion
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Description of Arguments
same as BAD
same as BCE
same as BPC
same as BFR
same as BOE
same as BCL
same as BCH
same as BLO
same as LPC
same as LFR
same as LCL
same as LCH
same as LLO
same as ITF
same as LBO
same as FRM
same as TFQ
same as TFT
same as TMD
same as TCR
same as TDR
same as TSI
8–39
Revision 5
Query
Response to
(Instruction Code
Command
and Qualifier)
OGC= OGC? OGC=aabcdfxxxhhh
OGC? hiiiijjjjjkxxxxxxlmnnn
OGC* ooopppppqxxxxxx
OGC#
OGC?n Where n=0 to 9
returns the OGC
portion of 1 of 10
stored configs
(see Description of
Arguments)
MGC= MGC? MGC=abcdddd.ddd
MGC? defghhhhh.hhhijkk.k
MGC* lmnoppp.ppqrrstxxx
MGC# AAAA.AAAABCDE
EEEE.EEEFGHIIIJJ
.JKLMxxxxxxNOPP
PPQRRRRRRRRR
RRRSTUVxxxxxxm
MATrrrr.rrrssss.sss
abxcedfffgggGGGh
xxxxxxxxxxxxxxxxx
xxxxxxxxxxxxxxxxx
MGC?n xxxxxxxxxxxxx
