Symbol Function
~ If a message is sent via a local modem to a distant-end device or ODU, the message was transmitted transparently through the local
(ASCII Code 126) modem. In the event of the distant-end device not responding, the local modem wil generate a response.
For example: >0000/RET~ (indicating that it has finished waiting for a response and is now ready for further comms).
+
This character warns the user that the command was accepted, but that other parameters were additionally changed.
(ASCII Code 43)
^ This code indicates that the modem is in Remote mode, so serial remote control is not possible. There are two exceptions to this:
(ASCII Code 94)
1.
2.
8.4.1.6

Optional Message Arguments

Arguments are not required for all messages.
Comma ',' (ASCII Code 44), period '.' (ASCII Code 46), the numbers '0' to '9' (ASCII Codes 48 to 57), and the uppercase alphabetic
characters 'A' to 'Z' (ASCII Codes 65 to 90) may be used.
8.4.1.7

End of Packet

Controller-to-Target
Target-to-Controller
Serial-based Remote Product Management
The LRS (Local/Remote Status) command is still active, and may be used to change the operating mode to local or to serial remote
control.
For the CDM/R-570AL, the FPL (Front Panel Lockout) command is active, and may be used to configure the Front Panel Lockout to
be "No lockout" or "Active."
This is the 'Carriage Return' ([CR]) character (ASCII code 13).
This is the two-character sequence 'Carriage Return', 'Line Feed' ([cr][lf]) (ASCII codes 13 and 10). Both indicate the valid
termination of a packet.
