6.3.7.9.3

UTIL: CID (Carrier ID) Phone#

CarrierID Phone #:
+15555555555
Edit the Carrier ID unit Phone Number on the bottom line, by using the ◄ ►arrow keys to select
an alphanumeric character space. Then, use the ▲▼ arrow keys to change that character. Press
ENTER.
The unit limits the Telephone Number to 18 alphanumeric characters or less, and limits the
selection of available characters as follows:
6.3.7.9.4

UTIL: CID (Carrier ID) Message

CarrierID Message:
Custom CarrierID Message
Compose a MetaCarrier Custom Message on the bottom line by using the ◄ ►arrow keys to
select an alphanumeric character space. Then, use the ▲▼ arrow keys to change that character.
Press ENTER.
You may use all printable ASCII characters, from [Space](0x20) through tilde ~ (0x7E), to
compose a MetaCarrier Custom Message of 24 characters or less.

6.3.8 SELECT: ODU (CDM-570A 70/140 MHz Unit ONLY)

See Chapter 10. CDM-570A/570AL ODU (TRANSCEIVER, BUC, LNB) M&C
OPERATIONS for complete details about this modem-specific menu branch.
Transceiver Control:
Disable Enable(◄ ►,ENTER)
Use this menu branch to monitor and control a Comtech EF Data RF Transceiver (CSAT-5060 or
KST-2000A/B), if connected.
Front Panel Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
[Space] 0-9 and x


