9.3.8.1.10 Satellite Modem > Configuration > BERT Configuration
Open the nested BERT Configuration page from the Configuration page.
Selection
BERT Tx State
BERT Rx State
BERT Tx Pattern
BERT Rx Pattern
Error Insert
Restart Monitor
Optional Packet Processor - Serial/Telnet CLI Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Figure 9-39. BERT (Bit Error Rate Test) Configuration
Hot Key
Select the BERT Tx or Rx operating mode:
A
1 – Off
B
2 – On
Select the BERT Tx or Rx pattern:
C
1 – 1:1
2 – 2047
3 – 2^15-1
D
4 – 2^23-1
I Select to insert an error into the ongoing BERT.
R Select to restart the BERT Monitor.
Description
