Comtech EF Data CDM-570A Installation And Operation Manual page 297

Command
Parameter (Instruction
Type Code and
Qualifier)
Outdoor Unit ODU= 1 byte,
Comms Enable value of 0 or 1
IP Address IPA= 18 bytes,
numerical
IP Gateway IPG= 15 bytes
numerical
MAC Address N/A 12 bytes,
Alphanumerical
Serial-based Remote Product Management
Arguments for
Command or
Response to
Query
Command or Query – CDM-570A Only.
Enables or disables communications, via the FSK link, with a Comtech EF Data
transceiver (ODU) in the form x, where:
0 = Disabled
1 = Enabled
Example: <0/ODU=0 (ODU disabled)
Command or Query.
Sets or returns the IP address and network prefix for the '10/100 M&C' 10/100
BaseT Ethernet management port, in the form xx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx is the IP address
yy is the network prefix (from 8 to 30)
Example: <0/IPA=010.006.030.001.24
Command or Query.
Sets or returns the IP Gateway Address for the Ethernet management port, in the
form aaa.bbb.ccc.ddd, where permitted ranges (all zeroes are not permitted) are:
aaa = 0–223
bbb = 0–255
ccc = 0–255
ddd = 0–255
Example: <0/IPG=010.006.030.001
Query only.
Returns the unique MAC Address for the modem.
Example: <0/MAC?
>0/MAC=0006B00001C2
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Description of Arguments
8–31
Revision 5
Query
Response to
(Instruction Code
Command
and Qualifier)
ODU= ODU? ODU=x
ODU? (see Description of
ODU* Arguments)
ODU#
IPA= IPA? IPA=
IPA? xxx.xxx.xxx.xxx.yy
IPA* (see Description of
IPA# Arguments)
IPG= IPG? IPG=
IPG? xxx.xxx.xxx.xxx
IPG* (see Description of
IPG# Arguments)
N/A MAC? MAC=aabbccddeeff
(see Description of
Arguments)
MN-CDM570A
Response to
Query
