The read-only screen shots that follow depict sample configurations – the actual
values and settings will vary and they are dependent on the ODU configuration
in use. Typical for all nested screens, press ENTER or CLEAR to return to the
(ODU: Enable: ► KST SELECT:) INFO menu.
(KST SELECT: ► INFO:) TX (TRANSMITTER)
TX: ON
AGC: OFF
This screen shows the KST-2000A transmitter status: Tx operating state (ON or OFF); Tx
Frequency; Tx Attenuation; and AGC state (ON or OFF).
(KST SELECT: ► INFO:) RX (RECEIVER)
RX: ON
Ref-Adjust: 228
This screen shows the KST-2000A receiver status: Rx operating state (ON or OFF); Rx
Frequency; Rx Attenuation; and Internal Reference adjustment.
(KST SELECT: ► INFO:) HPA
HPA: On
Fault Logic: No Summary
This screen shows the current HPA configuration: HPA (ON or OFF) and Fault Logic
(Summary or No Summary).
(KST SELECT: ► INFO:) LNA
LNA: On
Fault Logic: No Summary
This screen shows the current LNA configuration: LNA (ON or OFF) and Fault Logic
(Summary or No Summary).
(KST SELECT: ► INFO:) Equip (Equipment)
EQUIP-TYPE: KST-2000A
HPA-TYPE: CEFD-SSPA
This screen shows the currently installed ODUs: The transceiver, high-power amplifier, and
solid-state power amplifier.
ODU (Transceiver, BUC, LNB) Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
14500.0MHz 19dB
10950.0MHz 15dB
