Configuration | Wan | Compression - Comtech EF Data CDM-570A Installation And Operation Manual

7.4.3.3.6.2

Configuration | WAN | Compression

Use this page to configure the optional Payload and Header Compression, when this FAST
feature is enabled.
Compression
•
Header Comp. Refresh Rate for UDP/RTP1 – Enter the number of packets, from 1 to
600, required to trigger the Header Compression's User Datagram Protocol/Real Time
Protocol refresh rate.
•
Header Comp. Refresh Rate for UDP – Enter the number of packets, from 1 to 600,
required to trigger the Header Compression's User Datagram Protocol refresh rate.
•
Header Comp. Refresh Rate for all others – Enter the number of packets, from 1 to
600, required to trigger the Header Compression's Default Protocol refresh rate.
•
Payload Comp. Refresh Rate – Enter the number of packets, from 1 to 600, required
to trigger the Payload Compression's refresh rate.
Click [Submit] to save.
Make sure to also click [Save PaP Parameters] on the 'Admin | PaP Save' page
before proceeding further.
Ethernet-based Remote Product Management
CDM-570A/570AL Satellite Modem with Optional Packet Processor
Figure 7-27. Configuration | WAN | Compression Page
7–51
Revision 5
MN-CDM570A
