(CONFIG: Remote Control) Serial: Baudrate
Local M&C Bus Baud Rate:
19200 Baud
Valid baud rates (in bps) are 2400, 4800, 9600, 19200, 38400, or 57600.
Use the ▲▼arrow keys to select the baud rate of the remote M&C bus that is connected
locally to the User PC, bps. Press ENTER.
The asynchronous character format is FIXED at 8 data bits, 1 stop bit, no
parity (8-N-1).
6.3.2.1.2

(CONFIG:) Remote Control: Ethernet

In Ethernet mode, Serial monitoring is allowed; however, Serial control is not
allowed except for use of the LRS (Local/Remote Status) and FPL (Front Panel
Lockout) commands and queries.
Ethernet Config: Gateway
Address MAC SNMP
◄ ►
Use the arrow keys to select a parameter. Press ENTER.
(CONFIG: Remote Control) Ethernet: Gateway
Ethernet IP Gateway:
192.168.001.002
To edit the modem 'M&C' Ethernet port IP Gateway Address, use the
select a digit, and then use the ▲▼arrow keys to change that digit. Press ENTER.
(CONFIG: Remote Control) Ethernet: Address
Ether IP Address/Range:
192.168.001.002/24(◄ ►,▲ ▼)
To edit the modem 'M&C' Ethernet port management and data traffic IP Address and Range,
◄ ►
use the
Press ENTER.
(CONFIG: Remote Control) Ethernet: MAC
M&C Port MAC Address:
00-06-B0-00-01-06 (ENTER)
This read-only screen displays the unit MAC Address. Press ENTER or CLEAR to exit this
menu.
Front Panel Operation
CDM-570A/570AL Satellite Modem with Optional Packet Processor
(▲ ▼,ENTER)
(◄ ►)
(◄ ►,▲ ▼)
arrow keys to select a digit, and then use the ▲▼arrow keys to change that digit.
