Flash access control register (FLASH_ACR)
for STM32F42xxx and STM32F43xxx
The Flash access control register is used to enable/disable the acceleration features and
control the Flash memory access time according to CPU frequency.
Address offset: 0x00
Reset value: 0x0000 0000
Access: no wait state, word, half-word and byte access
31
30
29
28
15
14
13
12
DCRST ICRST
Reserved
rw
Bits 31:11 Reserved, must be kept cleared.
Bit 12 DCRST: Data cache reset
This bit can be written only when the D cache is disabled.
Bit 11 ICRST: Instruction cache reset
This bit can be written only when the I cache is disabled.
Bit 10 DCEN: Data cache enable
Bit 9 ICEN: Instruction cache enable
Bit 8 PRFTEN: Prefetch enable
Bits 7:4 Reserved, must be kept cleared.
Bits 3:0 LATENCY[2:0]: Latency
These bits represent the ratio of the CPU clock period to the Flash memory access time.
27
26
25
11
10
9
DCEN
ICEN
w
rw
rw
0: Data cache is not reset
1: Data cache is reset
0: Instruction cache is not reset
1: Instruction cache is reset
0: Data cache is disabled
1: Data cache is enabled
0: Instruction cache is disabled
1: Instruction cache is enabled
0: Prefetch is disabled
1: Prefetch is enabled
0000: Zero wait state
0001: One wait state
0010: Two wait states
...
1110: Fourteen wait states
1111: Fifteen wait states
DocID018909 Rev 11
24
23
22
Reserved
8
7
6
PRFTEN
Reserved
rw
Embedded Flash memory interface
21
20
19
18
5
4
3
2
LATENCY[2:0]
rw
rw
17
16
1
0
rw
rw
