Table 6. Flash module - 2 Mbyte dual bank organization (STM32F42xxx and STM32F43xxx)

Block
Main memory
Option bytes
Bank
Bank 1
Bank 2
System memory
OTP
Bank 1
Bank 2
DocID018909 Rev 11
Name Block base addresses
Sector 0 0x0800 0000 - 0x0800 3FFF
Sector 1 0x0800 4000 - 0x0800 7FFF
Sector 2 0x0800 8000 - 0x0800 BFFF
Sector 3 0x0800 C000 - 0x0800 FFFF
Sector 4 0x0801 0000 - 0x0801 FFFF
Sector 5 0x0802 0000 - 0x0803 FFFF
Sector 6 0x0804 0000 - 0x0805 FFFF
-
-
-
Sector 11 0x080E 0000 - 0x080F FFFF
Sector 12 0x0810 0000 - 0x0810 3FFF
Sector 13 0x0810 4000 - 0x0810 7FFF
Sector 14 0x0810 8000 - 0x0810 BFFF
Sector 15 0x0810 C000 - 0x0810 FFFF
Sector 16 0x0811 0000 - 0x0811 FFFF
Sector 17 0x0812 0000 - 0x0813 FFFF
Sector 18 0x0814 0000 - 0x0815 FFFF
Sector 23 0x081E 0000 - 0x081F FFFF
0x1FFF 0000 - 0x1FFF 77FF
0x1FFF 7800 - 0x1FFF 7A0F
0x1FFF C000 - 0x1FFF C00F
0x1FFE C000 - 0x1FFE C00F
Embedded Flash memory interface
-
-
-
-
-
-
Size
16 Kbytes
16 Kbytes
16 Kbytes
16 Kbyte
64 Kbytes
128 Kbytes
128 Kbytes
-
-
-
128 Kbytes
16 Kbytes
16 Kbytes
16 Kbytes
16 Kbytes
64 Kbytes
128 Kbytes
128 Kbytes
-
-
-
128 Kbytes
30 Kbytes
528 bytes
16 bytes
16 bytes
