Table 69. Fsmc_Btrx Bit Fields - ST STM32F423 Reference Manual

Flexible static memory controller (FSMC)
Bit number
12
11
10
9
8
7
6
5-4
3-2
1
0
Bit number
31-30
29:28
27-24
23-20
19-16
15-8
7-4
3-0
296/1324
Table 68. FSMC_BCRx bit fields (continued)
Bit name
WREN 0x1
WAITCFG 0x0
Reserved 0x0
WAITPOL to be set according to memory
BURSTEN no effect on synchronous write
Reserved 0x1
FACCEN Set according to memory support
MWID As needed
MTYP 0x1
MUXEN As needed
MBKEN 0x1

Table 69. FSMC_BTRx bit fields

Bit name
Reserved 0x0
ACCMOD 0x0
DATLAT Data latency
0x0 to get CLK = HCLK
CLKDIV
0x1 to get CLK = 2 × HCLK
BUSTURN Time between NEx high to NEx low (BUSTURN HCLK).
DATAST Don't care
ADDHLD Don't care
ADDSET Don't care
