AES hardware accelerator (AES)
Bits 31:0 KEY[95:64]: Cryptographic key, bits [95:64]
Refer to the AES_KEYR0 register for description of the KEY[255:0] bitfield.
24.7.8

AES key register 3 (AES_KEYR3)

Address offset: 0x1C
Reset value: 0x0000 0000
31 30 29 28
rw rw rw rw
15 14 13 12
rw rw rw rw
Bits 31:0 KEY[127:96]: Cryptographic key, bits [127:96]
Refer to the AES_KEYR0 register for description of the KEY[255:0] bitfield.
24.7.9

AES initialization vector register 0 (AES_IVR0)

Address offset: 0x20
Reset value: 0x0000 0000
31 30 29
rw rw rw
15 14 13
rw rw rw
Bits 31:0 IVI[31:0]: Initialization vector input, bits [31:0]
Refer to
IVI[127:0] bitfield.
The initialization vector is only used in chaining modes other than ECB.
The initialization vector may be written only when the AES peripheral is disabled.
24.7.10

AES initialization vector register 1 (AES_IVR1)

Address offset: 0x24
Reset value: 0x0000 0000
738/1324
27 26 25
rw rw rw
11 10 9
rw rw rw
28 27 26 25
rw rw rw rw
12 11 10 9
rw rw rw rw
Section 24.4.15: AES initialization vector registers on page 726
