USB on-the-go full-speed (OTG_FS)

33.15.46 OTG device control OUT endpoint 0 control register

(OTG_DOEPCTL0)

Address offset: 0xB00
Reset value: 0x0000 8000
This section describes the OTG_DOEPCTL0 register. Nonzero control endpoints use
registers for endpoints 1–3.
31 30 29
EPENA EPDIS Res. Res.
w r
15 14 13
USBA
Res. Res. Res.
EP
r
Bit 31 EPENA: Endpoint enable
The application sets this bit to start transmitting data on endpoint 0.
The core clears this bit before setting any of the following interrupts on this endpoint:
– SETUP phase done
– Endpoint disabled
– Transfer completed
Bit 30 EPDIS: Endpoint disable
The application cannot disable control OUT endpoint 0.
Bits 29:28 Reserved, must be kept at reset value.
Bit 27 SNAK: Set NAK
A write to this bit sets the NAK bit for the endpoint.
Using this bit, the application can control the transmission of NAK handshakes on an
endpoint. The core can also set this bit on a transfer completed interrupt, or after a SETUP
is received on the endpoint.
Bit 26 CNAK: Clear NAK
A write to this bit clears the NAK bit for the endpoint.
Bits 25:22 Reserved, must be kept at reset value.
Bit 21 STALL: STALL handshake
The application can only set this bit, and the core clears it, when a SETUP token is received
for this endpoint. If a NAK bit or Global OUT NAK is set along with this bit, the STALL bit
takes priority. Irrespective of this bit's setting, the core always responds to SETUP data
packets with an ACK handshake.
Bit 20 SNPM: Snoop mode
This bit configures the endpoint to Snoop mode. In Snoop mode, the core does not check
the correctness of OUT packets before transferring them to application memory.
Bits 19:18 EPTYP[1:0]: Endpoint type
Hardcoded to 2'b00 for control.
1218/1324
28 27 26 25
SNAK CNAK Res.
w w
12 11 10 9
Res. Res. Res.
24 23 22
Res. Res. Res. STALL
8 7 6
Res. Res. Res.
RM0430 Rev 8
21 20 19 18
SNPM EPTYP[1:0]
rs rw r r
5 4 3 2
Res. Res. Res. Res.
RM0430
17 16
NAK
Res.
STS
r
1 0
MPSIZ[1:0]
r r
