Add IP Solutions
Install the circuit packs
1. If replacing the TN799 circuit pack, install the TN799B/C circuit pack in the
slot vacated by the TN799 circuit pack.
2. For convenience install the TN2302AP circuit pack in the rightmost slot
vacated by the TN802 and where the adapter is connected to the
corresponding backplane connector. The other 2 slots are now available for
other circuit packs.
When you plug in the TN2302AP IP Media Processor, the circuit pack starts to
boot. The RED LED stays on until an IP address is assigned to the circuit pack.
3. Type list configuration all and press
recognizes the TN2302AP circuit packs.
Administration Steps
1. Administer the TN799B/C C-LAN. Refer to the Administration for Network
Connectivity for Avaya MultiVantage Software.
2. Administer the IP Media Processor, which is usually done remotely. Call
your service representative to start the process.
3. Complete the administration and testing. Refer to
Steps for C-LAN and IP Media Processor'' on page 7-62
External Connection to the LAN'' on page
Upgrading a TN802B IP Interface Assembly to

TN2302AP IP Media Processor

To upgrade an IP Interface Assembly to IP Media Processor, you must replace
The TN802B circuit pack with a TN2302AP circuit pack
The TN799 circuit pack with a TN799B/C circuit pack, if necessary
The H600-512, G1 external cable assembly with an IP Media Processor
adapter.
Pre-upgrade steps
1. Type change ip-interfaces and press
555-233-115
to verify that the system
Enter
''Initial Administration
and
7-64.
.
Enter
Issue 5 October 2002
''Test the
7-67
