Add a Switch Node Carrier
.
ROW 49
.
.
.
.
ROW 35
ROW 25
SLOT #
ROW 24
Figure 6-32. ICC Connections for Switch Node Carrier
Install New Switch Node Carrier
NOTE:
Although the procedures specify D position, they would be the same if
installing the carrier in the E position.
1. Install the J58890SA switch node carrier in position D by lining up the
plastic alignment tips on the top rear of the carrier with the screw holes in
the cabinet. These alignment tips will support the carrier while the screws
are being replaced. Ensure that the power cords are properly placed in the
slots at the sides of the carrier.
2. Fasten the carrier into position with 4 self-tapping screws saved from the
removal of the old carrier.
!
3. Behind the carrier, replace the 2 screws saved from the removal of the old
carrier.
555-233-115
. . .
. . .
. . .
. . .
. . .
04 03
CAUTION:
Carefully realign the threads on the self-tapping screws by turning
them clockwise 1 turn before tightening them to avoid stripping the
threads out of the framework.
. . . . . . . . . . .
. . . . . . . . . . .
. . . . . . . . . . .
. . . . . . . . . . .
. . . . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
. . . . . . . . .
SNITRM1 TDM/LAN TDM/LAN
02 01
SNITRM2
. . . .
. . . .
. . . .
. . . .
Issue 5 October 2002
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
. . . . . . .
00
6-61
