Interconnect Port Networks with Fiber Optic Cabling
2. Behind control cabinet A of EPN stack 2:
a. Install a lightwave transceiver on the connector at slot 2A01.
b. Connect a fiber cable to the transceiver just installed.
c. Route the fiber cable down the outside of the rear covers and
d. Connect the fiber cable to the lightguide interface unit provided.
e. Carefully attach the fiber optic cable (with cable ties) to the rear
f. Coil the surplus fiber optic cable and place it in the cable manager.
Figure Notes
1. Lightwave Transceiver
2. To PPN Carrier B Slot 1C02
3. To EPN 1 Carrier A Slot 2A01
(Cabinet Stack 2)
4. Fiber Optic Cable
Figure 4-14. Fiber Optic Connections PPN to EPN1
555-233-115
NOTE:
Attenuators may be required for single mode fiber using a
300A Lightwave Transceiver
through the cable manager to the PDS cross-connect facility.
covers of the EPN stack.
RX TX
2 1
1
2
2
1
1
2
2
5. Fiber Optic Cross-Connect Facility
6. Lightguide Interface Unit (LIU)
7. TX Connector
8. RX Connector
Issue 5 October 2002
1
cydf013 CJL102396
4-51
