Interconnect Port Networks with Fiber Optic Cabling
Figure Notes
1. Lightwave Transceiver
2. To EPN Carrier A Slot 2A02
3. To EPN 1 Carrier A Slot 3A02
Figure 5-23. Fiber Optic Connections EPN1 to EPN2
For Either One or Two Fiber-Remoted Expansion Port Networks
1. At control carrier A of PPN cabinet 1 (see
555-233-115
RX TX
2 1
Install a lightwave transceiver on the cable connector at slot 1A01.
NOTE:
Attenuators may be required for single mode fiber using a
300A Lightwave Transceiver
Connect a fiber optic cable to the transceiver just installed.
Route the cable to the cable tray and down, out of the cabinet,
through the cable manager to the PDS cross-connect facility.
Connect the cable to the lightguide interconnect unit provided.
Carefully attach the fiber optic cable (with cable ties) to the wall of
the cable tray at the built-in cable tie positions.
2
4. Fiber Optic Cable
5. RX Connection
6. TX Connection
Figure 5-25 through
Issue 5 October 2002
1
cydff05 CJL 103196
Figure 5-9):
