Upgrading G3rV4 and R5/6/7/8r to Avaya DEFINITY
Server R running Avaya MultiVantage Software
Tape Drive: Lock to SPE B
(High/Critical reliability only)
1. Move the SPE-SELECT switches to the right (SPE B) on both Duplication
Interface (DUPINT) circuit packs, one at a time.

Tape Drive: Power Down SPE A

!
CAUTION:
Do not power down the whole cabinet; it is not necessary.
NOTE:
If there are two power supplies, power down the SPE by removing the
power plug on the left side of the carrier then by removing the power plug on
the right side of the carrier. If there is only one power supply, remove the one
power plug on the right side.
For standard reliability, power down the SPE. This causes a service interruption.
For high or critical reliability, power down the standby SPE only.

Remove the UN332B and Tape Drive

1. Remove the blank faceplate next to the MSSNET slot in the carrier.
2. Remove the UN332B circuit pack from the carrier and place it in antistatic
packing material.
3. Remove the tape from the tape drive.
4. Remove the TN1656 tape drive and place it in antistatic packing material.

Install the UN332C and Optical Drive

NOTE:
To properly seat a circuit pack, push firmly on the front of the faceplate until
the latch reaches the bottom rail of the carrier. Then close the latch until it is
fully engaged.
1. Insert the UN332C circuit pack into the MSSNET slot.
2. Replace the blank faceplate next to the MSSNET circuit pack.
3. Insert the TN2211 optical drive into the rightmost TAPE DRIVE slot. It uses
only 2 slots.
2-30
Issue 5 October 2002 555-233-115
