Install the EPN
Interconnect Port Networks
You must next install all the fiber optic cabling and then administer it. For the
installation procedure, refer to
Cabling'' on page
Connect Power and Ground
1. Reconnect the 6 AWG (#40) (4.1 mm
single-point ground bar on the cabinet.
2. Reconnect the 10 AWG (#25) (2.6 mm
3. Reconnect the cabinet power cords at the rear of each cabinet.
Verify Usable Circuit Pack Vintages
1. Verify every circuit pack reused in the upgrade conforms to the usable
vintage requirements.
Install System Access Ports
1. Before connecting various endpoints that use EIA interfaces to the system,
install up to 8 loop-around connections for Mode 2-to-Mode 3 (and vice
versa) data conversion.
From the outgoing perspective of the system communicating with an EIA
endpoint, these loop-around connections convert Mode 3 data (circuit-switched
packet data, with undefined bit rates and packet specifications) to Mode 2 data
(low-speed, usually asynchronous, data at rates of 300 to 19,200 bps) by:
Accepting Mode 3 data off the LAN bus (from the SPE) at a TN553 Packet
Data Line circuit pack, where Mode 3-to-Mode 2 conversion is done
Routing the converted data through the cross-connect field and back to a
TN726B Data Line where the equivalent Mode 2 data can access the TDM
bus, for subsequent routing to an EIA endpoint
The endpoints that use these EIA interfaces and, therefore, require the Mode
2-to-Mode 3 conversion include:
Generic 3 Management Applications (G3-MA)
Remote Management Terminal or local PC
Basic Call Management System (BCMS) terminal
Call Detail Recording Unit (CDRU)
Property Management System (PMS)
Printers
555-233-115
''Interconnect Port Networks with Fiber Optic
4-40.
2
) cabinet ground wire to the
2
) coupled bonding conductor wire.
