Upgrading a Multicarrier G2 Universal Module to Avaya
DEFINITY Server R EPN running Avaya MultiVantage
Software
Figure Notes
1. Lightwave Transceiver
2. To PPN Carrier C Slot 1C02
3. To EPN 1 Carrier A Slot 2A01
Figure 5-21. Fiber Optic Connections PPN to EPN1
Figure Notes
1. Lightwave Transceiver
2. To PPN Carrier A Slot 1D02
3. To EPN 1 Carrier A Slot 3A01
Figure 5-22. Fiber Optic Connections PPN to EPN2
5-108
Issue 5 October 2002
RX TX
2 1
RX TX
2 1
2
4. Fiber Optic Cable
5. RX Connection
6. TX Connection
2
4. Fiber Optic Cable
5. RX Connection
6. TX Connection
1
cydff05 CJL 103196
1
cydff05 CJL 103196
555-233-115
