Adding or Removing Cabinet Hardware
.
change ip-interfaces
Network regions are interconnected?
En-
abled Type
Addr Rgn
n
C-LAN 01A09 TN799
y
MEDPRO 01A13 TN802 B med-a1
n
n
n
n
n
n
n
n
n
n
n
n
n
Test the External Connection to the LAN
To test the external IP connections, ping the IP Interface server, and ping a known
computer connected to your network. If everything is configured correctly, the
Result column on the Ping Results screen reads pass. If it reads abort, verify
the IP-address information and check the connectivity, including the cabling.
1. Type ping ip-address nnn.nnn.nnn.nnn board UUCSS and press
The variable nnn.nnn.nnn.nnn is the IP address of the TN802B IP
Interface and UUCSS is the cabinet, carrier, and slot of the TN802B IP
Interface.
ping ip-address 192.168.10.21
End-pt IP
192.168.10.21
2. Type ping ip-address nnn.nnn.nnn.nnn board UUCSS and press
The variable nnn.nnn.nnn.nnn is the IP address of the customer's
gateway and UUCSS is the cabinet, carrier, and slot of the TN802B IP
Interface.
3. Type ping ip-address nnn.nnn.nnn.nnn board UUCSS and press
The variable nnn.nnn.nnn.nnn is the IP address of another computer
beyond the gateway and UUCSS is the cabinet, carrier, and slot of the
TN802B IP Interface.
The TN802B IP Interface is now installed in the carrier and connected to the IP
network.
7-80
Issue 5 October 2002
Slot
Code Sfx Node Name
clan-a1
PING RESULTS
Port
Port Type
01A13
MEDPRO
Page
n
Subnet Mask
255.255.255.0
192.168.1 .100 1
255.255.255.0
192.168.1 .21 1
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
Result
Time(ms)
PASS
10
1 of
2
Net
Bcast/Gway
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Enter.
Error Code
1124
Enter.
Enter.
555-233-115
