Interconnect Port Networks with Fiber Optic Cabling

Figure Notes

1. Lightwave Transceiver

2. To PPN Carrier A Slot 1A02

3. To EPN2 Carrier A Slot 3A01

4. To PPN Carrier B Slot 1B02

5. To EPN2 Carrier B Slot 3B02

Figure 5-34. Fiber Optic Connections PPN to EPN2

6. Fiber Optic Cable

7. Optical Cross-Connect Facility

8. 100A Lightguide Interconnect Unit

9. TX Connector

10. RX Connector

Issue 5 October 2002
