Avaya DEFINITY Server R Manual page 435

Downloading Firmware to Port Circuit Packs
Preparation
1. Repeat the procedures in the
7-8.
Set up file system on circuit pack
Before you can load files onto the source C-LAN circuit pack, you must first set up
a file system on the circuit pack to accept the files.
1. Log into the switch using a superuser or services login and password.
2. Enter enable filesystem board UUCSS login ftplogin ftppassword [size
actual_size], where:
Later, you will use this same ftplogin and ftppassword in the section,
''FTP the new firmware image file'' on page
!
FTP the new firmware image file
The following steps are generic to most FTP programs. Use your laptop/PC/UNIX
to complete this procedure.
1. Ensure that the new firmware image file is in the same directory where you
will launch the FTP session.
2. Enter ping source_ip_address to verify a communication link to the
source C-LAN board.
3. Enter ftp source_ip_address.
555-233-115
ftplogin is any temporary login ID for this FTP session (for example,
denver).
ftppassword is any ≥ 7-character temporary password for this FTP
session (for example, broncos).
NOTE:
The optional size actual_size qualifier only works with TN799C
(C-LAN). It allows you to specify a smaller file-system size than the
default 1-MB block (maximum) allocated.
If the source circuit pack does not have enough available memory,
delete old files (remove file board UUCSS filename), or wait until
there is less traffic on the board.
CAUTION:
Unless the Remove Image File After Successful Download
field is set to y, the ftplogin and ftppassword remain on the TN799DP
(C-LAN) and TN2501AP (VAL) circuit packs either until they are reset
or until you issue the disable filesystem board UUCSS command.
''Preparing to Update Firmware'' on page
7-12.
Issue 5 October 2002
7-19
