Upgrading a Multicarrier G2 Universal Module to Avaya
DEFINITY Server R EPN running Avaya MultiVantage
Software
Remove CURL from Module Control Carrier A
Remove the CFY1 current limiter (CURL) from the pin-field block marked "CURL"
on the "A" carrier. The CURL will be reused in the new EPN.
NOTE:
Verify that the CURL meets the minimum usable vintage requirements.
Remove Module Control Carrier A
1. Disconnect both TDM/LAN cables from the "A" carrier. See
Leave the other end connected to the "C" carrier.
!
2. On port carrier J58890BB-1, connect the TDM cable or TDM terminator to
Slot 02. On port carriers J58890BB-2 and J58890BB-3, connect the TDM
cables to Slot 01.
5-46
Issue 5 October 2002
NOTE:
Note the position of each TDM/LAN cables before disconnecting.
CAUTION:
When removing the TDM/LAN cables from a previously upgraded
carrier, be careful that none of the short pieces of shrink tubing come
off the 4 corner pins of the pin-field block. Otherwise, when the new
equipment is connected, -48 volts could short to ground.
Figure 5-5.
555-233-115
