Upgrades and additions

Hide thumbs Also See for DEFINITY Server R:

Table of Contents

Remove Module Control Carrier(s)

Figure Notes

1. Port Carrier ("C" Position)

2. ZAHF4 TDM/LAN Terminator

3. TDM/LAN Cable (WP91716 L6)

4. Module Control Carrier ("A" Position)

5. Port Carrier ("D" Position)

Figure 5-1. TDM/LAN Connections for Control Module (Standard Reliability)

6. Port Carrier ("E" Position)

9. TDM/LAN Cable (WP91716 L7)

Issue 5 October 2002
