9.3 SAB

9.3.1 Troubleshooting

Table 9.4 lists potential faults on the SAB, their possible
causes, and actions for correcting the faults.
Fault
LCP display dark
or has no
function.
372
Signal name PLC library -
trace constant name
Rotor position logical ISD51x_TRC_ROTOR_POS_ACT_VIRT
Following error ISD51x_TRC_PCTRL_LAG_ERROR
Rotor mech angle raw ISD51x_TRC_ROTOR_POS_RAW
Rotor speed relative –
Position ctrl set ISD51x_TRC_PCTRL_POS_SET
Logical CAM setpoint ISD51x_TRC_CAM_POS_SET
Cam velocity set ISD51x_TRC_CAM_N_SET
Controlword ISD51x_TRC_CONTROLWORD
Statusword ISD51x_TRC_STATUSWORD
Motion and input status ISD51x_TRC_MOTION_AND_INPUT
Cam profile status ISD51x_TRC_CAM_PROFILE_STATUS
Logical CAM setpoint scaled –
CAM friction torque ISD51x_TRC_CAM_FRICTION_COMP
Position actual value ISD51x_TRC_POSITION_ACTUAL_VALUE Actual position in user-defined units
Velocity actual value ISD51x_TRC_DS402_VELOCITY_ACT_VAL Actual velocity in user-defined units
Torque actual value ISD51x_TRC_TORQUE_ACTUAL_VALUE
Following error actual value ISD51x_TRC_DS402_FOLLOW_ERR
Position guide value reference ISD51x_TRC_GUIDE_REF_VAL_POS
Velocity guide value reference ISD51x_TRC_GUIDE_REF_VAL_SPEED
Possible cause Possible solution
Missing input Check the input power
power. source.
Missing or open Check the fuses and circuit
fuses or circuit breaker.
breaker tripped.
•
No power to the Check the LCP cable for
LCP. proper connection or
damage.
•
Replace any faulty LCP
or connection cables.
Incorrect
Press [Status] + [
contrast setting.
adjust the contrast.
Display is Replace the faulty LCP or
defective. connection cable.
