Servo Drive Operation
Attribute
Mandatory/
optional
2
2
(+default
value)
velocity
O; default =
Limit
maximum
exitCond
Same as in Table 2.26.
startAction
Same as in Table 2.26.
endAction
Same as in Table 2.26.
Table 2.31 Attributes for TorqueSegment in Start/Endpoint
Representation
Coefficient representation: This representation is not
available.
PwmOffSegment:
The PwmOffSegment is used to turn off the PWM. Enabling
the PWM again afterwards takes some time.
Illustration 2.100 Start/Endpoint Representation
Attribute
segID
precNode
succNode
default
startPos
duration
exitCond
startAction
endAction
Table 2.32 Attributes for PwMOffSegment in Start/Endpoint
Representation
66
Value range/
Description
allowed values
Float >0
Configures the
maximum velocity
that can be used
during this
segment (absolute
value). The
velocity must be
given in rps.
When limit is
reached, no more
torque is
generated until
velocity is below
limit again.
Mandatory/
Value
Description
optional
range/
(+default
allowed
value)
values
Same as in Table 2.26.
Same as in Table 2.26.
Same as in Table 2.26.
Same as in Table 2.26.
Same as in Table 2.18.
Same as in Table 2.26.
Same as in Table 2.26.
Same as in Table 2.26.
Same as in Table 2.26.
Danfoss A/S © 01/2017 All rights reserved.
®
VLT
Integrated Servo Drive ISD
Coefficient representation: This representation is not
available.
FrictionSegment:
The FrictionSegment is used to first measure the friction of
the servo drive system at 2 different velocities. This friction
can either be used for long-term monitoring or the servo
drive can use it for an automatic compensation. The
measurement occurs alternating (over the guide value
cycles) with velocityLow and with velocityHigh.
This segment ends either with the defined velocityLow or
velocityHigh.
Illustration 2.101 Start/Endpoint Representation
Attribute
segID
precNode
succNode
default
startPos
duration
velocityLow
velocityHigh
doCompen-
sation
®
510 System
Mandato
Value
Description
ry/
range/
optional
allowed
(+default
values
value)
Same as in Table 2.26.
Same as in Table 2.26.
Same as in Table 2.26.
Same as in Table 2.26.
Same as in Table 2.18.
Same as in Table 2.26.
M
Float
Velocity of the axis
during the first part of
the measurement. The
velocity must be given
in rps.
O; no
Float
Velocity of the axis
default
during this segment. The
exists
velocity must be given
in rps. To ensure smooth
movements, the
velocities of all segments
that are connected in
the same node should
be the same. If this is
not parameterized
correctly, a jump in
velocity will occur.
O;
TRUE/FALSE If TRUE, the measured
default =
friction is compensated
FALSE
automatically by the
servo drive. If FALSE, the
value can be used for
diagnostics.
MG36D102
